Cameroon Aluzinc Roofing Sheet Corrugation Machine for Short Span and Long Span Roof Caldding
Introduction
This roll forming machine is making roofing sheets in the shape of a corrugated profile, (refered to as Wave Profile) which lap together side to side and end to end, making it very easy to cover varying areas of roof quickly. The profiled roof sheets made by this machine are typically aluzinc steel or aluminium. The finished cameroon zinc roofing sheets are popular in African countries like Nigeria, Ghana, Malawi, Sierra Leone and so on.
Cameroon Aluzinc Roof Panel Roll Forming Machine Corrugated Sheet Making Machine
Working Flow
Decoiling---->Sheet Guilding---->Corrugating---->Cutting---->Finished Cameroun Zinc Roof Sheets
Main Components of Cameroon Alu Zinc Roof Sheet Corrugating Machine
1 Coil Decoiler 1 set
2 Main Roll Former Machine
Direction Guilder 1 set
Rolling System 1 set
Post-cutting Device 1 set
3 Supporting Tables for Finished Products 2 sets
4 Hydraulic Station for Cutting Device 1 set
5 PLC Control Cabinet 1 set
6 Tools Box with Spare Parts 1 set
Technical Specifications Cameroon Alu Zinc Roof Sheet Corrugating Machine
Raw Material Type: Aluminium & Steel Coils, PPGI, GI, PPGL
Width 914 mm; Thickness 0.15-0.30 mm or 0.30-0.70mm; Yield Strength 235-345 MPa or 550 MPa
Finished Products Cover width 762 mm; Length Adjustable
Required Power Voltage: 220V/380V/415V/440V
Driving Motor: 5.5 KW; Cutting Motor: 2.2 KW
Production Speed: 900-1200 meters per hour
Coil Decoiler Type: Un-powered or Powered; Capacity 5 tons
Rolling Stations of Roll Former: 18 sets
Rolling Shaft Diameter: 72 mm
Cutting Type: Post-cutting
Operation System: Mitsubishi PLC, transducer and touching screen
Supporting Tables: 2 sets
Machine Size: Around 8.3 x 1.5 x 1.5 meters
Machine Weight: Around 7 tons
Applications of Corrugated Roofing Sheets: Low cost and strong roof building
We are supplying all kinds of oven baked aluminium roofing sheets making machines, such as box prfiled longspan metral roofing sheet corrugating machine, normal steptile roof sheet making machine, metcopo step tile roof sheet corrugation machine, cameroon aluzinc roof sheet making machine, ridge cap manufacturing machine and so on. If you want to get more details about this Cameroon Aluzinc Roof Panel Roll Forming Machine Corrugated Sheet Making Machine, please contact us by the following information!
Email: metalrollformer@yahoo.com
Mobile: +0086 158 6814 2550
