Double Layer Roofing Sheet Panel Roll Forming Machine
Offered by wxtechwell, Independent, Thu, 09/26/2024 - 06:58, Company, Others
<
>
Contact Advertiser
Safety Tips
- Do not pay in advance even for the delivery.
- Try to meet at a safe or public location.
- Check the item BEFORE you buy it.
- Pay only after collecting the item
Description
Other Details
2 in 1 Double Layer Roofing Sheet Roll Forming Machine, Double Layer Roof Panel Roll Forming Machine,Double Layer Roll Forming Machine
A) Technical Data
1. Decoiler: Hydraulic Decoiler
2. Weight Capacity Of Decoiler: 5 Ton
3. Main Motor Power: 7.5 Kw
4. Hydraulic Motor Power: 3 Kw
5. Roll Stand: upper 18, lower 18
6. Raw Material Width: 1000 mm
7. Thickness Of Raw Material: 0.3-0.8 mm
8. Necessary Covered Width: depend on profiles
9. Machine Frame stand: Welded structural steel
10.Thickmess of Fame Steel: 18mm
11. Type of forming machine: Single station with chain transmission
12. Material of Roller: High grade 45# forge steel, Polished and coated with 0.05mm Chrome Surface.
13. Transporting Type: Chain Transmission
14. Material Of Chain: High Grade 45#, Heated and quenched HRC 45-50
15. Main Axis Material: High grade 45#
16. Axis Diameter: 70mm
17. Working Speed: 15-20 m/min
18. Voltage: 380V, 3 Phase 50Hz
19. Material Of Blade: C r 12
20. Heat Treatment of Cutting Blade: HRC 50-60
21. Type of Cutting: Hydraulic cutting
22. Electrical Control: PLC Frequency Control System with touch screen
Our Main Machine:
Roll Forming Machine, EPS / Rock Wool / Glass Wool / Mineral Wool / PU Sandwich Panel Machine Line, Roof Tile Roll Forming Machine, Hidden-Joint Roof Tile Roll Forming Machine, Wall Panel Roll Forming Machine, Hidden-Joint Wall Panel Roll Forming Machine, Glazed Tile Roll Forming Machine, Corrugated Sheet Roll Forming Machine, Double Layer Roll Forming Machine, C / Z / U / W Shape Purlin Roll Forming Machine, Ridge Cap Roll Forming Machine, Highway Guardrail Roll Forming Machine, Downpipe Roll Forming Machine, Door Frame Forming Machine, Light Steel Keel Roll Forming Machine, U Channel Roll Forming Machien, Furring Channel Roll Forming Machine, No-Girder Curve Roof Panel Forming Machine, K-Span Roll Forming Machine, Large-Span Curve Roof Panel Roll Forming Machine, Roller Shutter Door Forming Machine, Crimped / Corrugated curving Machine, Curving Machine, Hydraulic Shearing Machine, Metal Sheet Folding Machine...
----------------------------
Company: Wuxi Techwell Machinery Manufacturing Co.,Ltd
Video Center: www.youtube.com/wxtechwell
Web: www.wxtechwell.com
www.cold-rollformingmachine.com
www.roofrollformingmachine.com
Mobile: +86-18018304331
Email: monica@wxtechwell.com
MSN: lixiaohua_monica@hotmail.com
Skype: monica198614
